Héctor here, your AFM expert at Nanosurf calling out for people to share their Friday afternoon experiments. Today I show you how I embed cells in a collagen matrix. This is a proof of concept for those interested in tissue engineering, to know how to obtain a test sample for their AFMs.

  • First, the collagen matrix.

A few weeks ago, I posted the fridayAFM "Secrets of the egg shell" and showed how it is relatively easy to obtain a collagen matrix. I did it because egg shell membrane has become a hot topic for its potential applications in bioengineering (see Ref 1), and it felt like having a simple procedure to prepare the sample and perform AFM was something useful. Also, because I saw many SEM images, but few taken with an AFM, so I wanted to add some data to make other people's journey easier (speaking of which, have you checked the mouse tail collagen images in our image gallery?) .

intro-3

At the time, I left it as an open challenge to try embedding things in that matrix, because one major line of research at the moment is to use egg shell membrane as scaffold for tissue engineering (see Ref 2 for instance on how to use eggshell membrane to repair skin). So, today I'll be showing exactly that, how to embed cells in the egg shell membrane, and I start by recreating the same result I got in the previous fridayAFM. I opened one egg (see image below), peeled the membrane, put it on top of a glass slide and let it dry for about one hour (slimy side down to help with the adhesion to the glass slide).

yeast and egg-2
1 Preparation of collagen matrix by peeling off the egg shell membrane. AFM images taken in Dynamic mode using Multi 75E probes.

So far, the same result, nothing new here, but it is always good practice to double check procedures. In my life I spent many hours measuring things that were not there in the end, so trust me and don't skip steps, measure twice, cut once.

  • Then the test subject: small beads.

Before trying to embed cells, I decided to try something smaller, and in principle easier to prepare, in this way, I might be able to differentiate if the problem is the embedding or the cells. So, what I can use?

The answer was in a much older fridayAFM when I imaged marker ink on paper. It turns out that the ink was made of tiny beads in a suspension, and once the liquid dries out, the beads attach easily to the surface and are easy to identify (and to image).

paper and ink
1 Paper and ink, fridayAFM from 2022 10 28. Same area imaged before/after applying ink from a marker.
Default image alt text
2 An optional caption for the image that will be added to the gallery. Enter any descriptive text for this image that you would like visitors to be able to read.
Default image alt text
3 An optional caption for the image that will be added to the gallery. Enter any descriptive text for this image that you would like visitors to be able to read.
Default image alt text
4 An optional caption for the image that will be added to the gallery. Enter any descriptive text for this image that you would like visitors to be able to read.
Default image alt text
5 An optional caption for the image that will be added to the gallery. Enter any descriptive text for this image that you would like visitors to be able to read.

The question is, if the marker is applied to the egg shell membrane, will the beads attach to the collagen fibers? Will the beads penetrate inside? I'm not sure if the liquid that carries the beads in suspension will wet the collagen or not, but if it does, maybe it passes through the membrane and washes away the beads. There are many possible scenarios. But if they stay within the membrane and I can image them, then it means the membrane can be used to trap things and they are stable enough for imaging. Not the same size and behaviour as cells, but close enough if it works, and it will be similar to functionalizing the egg shell membrane with nanoparticles, which is a very active area of research (see Refs 3 and 4).

So, I peeled a new membrane piece, mounted on the glass slide as before, painted it with the marker as if I using it to highlight text, and then let it dry for about one hour.

yeast and egg 2-1
1 Embedding beads from marker onto egg shell membrane to create nanoparticle-decorated collagen matrix. AFM images taken in Dynamic mode with Multi 75E probes.

It worked nicely... once I used the same brand of marker as the one I used before with paper. I don't want to digress here, but maybe the marker I tried was "dry", or despite looking similar, the composition of the markers is very different, figuring out the reason will take a lot of time, so at the moment I stick to exactly the same recipe.

If you are working with nanoparticle functionalization, this could be a good test sample to see if you can attach nanoparticles or how they degrade, or if a particular treatment washes the particles away... the limit is your imagination. The important thing is that with this knowledge, we can go for the next challenge, something big.

  • And at last, the embedding with yeast.

Yeast is going to be the unicellular organism that will try to embed in the egg shell membrane. To do so I used the knowledge I gained with yet another fridayAFM, when I showed how to prepare a yeast sample to image in air.

intro-Oct-16-2023-07-39-32-5977-PM

I started by preparing the egg shell membrane on a glass slide. Then, after half an hour or so (while it was still visible wet), I prepared the yeast using water, sugar and instant yeast (as in the fridayAFM mentioned above). Then the extra step, I dipped the membrane on the yeast 3 times for a few seconds each time. I left it drying for an hour before imaging.

yeast and egg 3-1
1 Embedding of yeast on the egg shell collagen matrix.

Did it work?

Judge fpr yourselves.

yeast and egg 4-1
1 AFM images taken in Dynamic mode with a Multi 75E probe.

Surprisingly, despite no optimization, it did work. It is possible to see some yeast cells on top of the matrix, but also embedded within the matrix. Did I remove the nutrients too early? Probably some more time hydrated would have allowed the yeast inside of the matrix to grow and generate new cells filling all the available space. But for a Friday afternoon test this is all that I managed to do, and demonstrates that it works.

Now you know how to prepare test samples with small and large objects using a collagen matrix as scaffolding. I hope you find it useful, and if you use it in your daily routine in the lab, please let me know, and as usual, if you have suggestions or requests, don't hesitate to contact me.

Further reading: check out our app note on live cell AFM imaging or the bio sciences section of both our Drive and Flex systems (both have cool images, I promise).



References:

1 Rosemond A Mensah et al The chicken eggshell membrane: a versatile, sustainable, biological material for translational biomedical applications. (2023) Biomed. Mater. 18 042001. https://doi.org/10.1088/1748-605X/acd316

2 Hee Jung Choi, Young Min Kim, Jeong-Yong Suh, Jae Yong Han, Beneficial effect on rapid skin wound healing through carboxylic acid-treated chicken eggshell membrane. (2021) Materials Science and Engineering: C, 128, 112350. https://doi.org/10.1016/j.msec.2021.112350

3 Ding, Q., Kang, Z., He, X. et al. Eggshell membrane-templated gold nanoparticles as a flexible SERS substrate for detection of thiabendazole. Microchim Acta 186, 453 (2019). https://doi.org/10.1007/s00604-019-3543-1

4 Preetam Guha Ray, Shreya Biswas, Trina Roy, Saptarshi Ghosh, Deblina Majumder, Piyali Basak, Somenath Roy, and Santanu Dhara. Sonication Assisted Hierarchical Decoration of Ag-NP on Zinc Oxide Nanoflower Impregnated Eggshell Membrane: Evaluation of Antibacterial Activity and in Vitro Cytocompatibility ACS Sustainable Chemistry & Engineering  (2019) 7 (16), 13717-13733. https://doi.org/10.1021/acssuschemeng.9b01185
